Nitrous Express Pumpless Water Injection 4150 Carburetor Plate - ( Nitrous Express 15140 )

NX direct port water methanol systems inject the water methanol mixture directly into each intake runner providing excellent distribution to each cylinder. These systems include a high pressure electric pump, stainless steel hard lines, filtered nozzles, nickel plated fittings and a composite reservoir. Stage one systems include a wide open throttle activation switch while stage 2 and stage 3 systems include digital progressive controllers that control water methanol output. Stage 2 controllers are adjusted by setting rotary dials on the progressive box. Stage 3 controllers include a LCD display and can be finely adjusted for low, mid and high airflow levels. The LCD Screen displays boost pressure, fuel injector duty cycle, as well as water-methanol injection percent.

NX Pumpless Direct port water methanol systems inject the water methanol mixture directly into each intake runner providing excellent distribution to each cylinder. These systems include a pressurized reservoir and pressure regulator that eliminates the need for an electric pump. These systems include braided stainless AN hoses, billet distribution blocks, filtered nozzles and nickel plated fitting

Nitrous Express Pumpless Water Injection 4150 Carburetor Plate

PUMPLESS WATER METHANOL 4150 CARBURETOR PLATE

Water Methanol; 4150; Carbureted; Pumpless

Water Methanol, 4150, Carbureted, Pumpless

Water / Methanol Injection System

Nitrous PUMPLESS WATER METHA

PUMPLESS WATER METHA

Wtr/MethInjSystm
